32Inch Lcd Digital Signage Display Windows System LG/ Screen Touch Kiosk
Quick Detail:
Ⅰ,
Place of original: Shenzhen Guangdong China(mainland)
creen size: 32 "
Resolution: 1920 (RGB) × 1080 [FHD]
Brightness (cd / m2): 500 (Typ.)
Best angle: full view
Viewing angle: 89/89/89/89 (Min.) (CR≥10)
Point distance: 0.227mm (H) x 0.227mm (W)
Number of colors: 16.7M / 1.07B, 95% [CIE1931]
Screen Weight: 6.30Kgs (Typ./Max.)
Signal system: LVDS (2 ch, 10-bit), terminal, 51 pins
Maximum rated: Storage temperature: -20 ~ 60 ° C Operating temperature: 0 ~ 50 ° Cw
Response speed: 6 (Typ.) (G to G) ms
Ⅱ,
Backlight type: WLED, 30K hours, no drive
CPU: RK3288, quad-core, frequency 1.6GHz
Memory: 1 / 2G (optional)
Built-in memory: EMMC FLASH 8G (optional)
Built-in ROM: 2KB EEPROM
Decoding resolution: up to 1080P
Operating system: Android 4.4 above
Play mode: support for the cycle, timing, spots and other playback modes
Network support: 3G, Ethernet, WiFi support, wireless peripherals expansion
Video playback: support wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 and so on
Picture format: support BMP, JPEG, PNG, GIF
Description:
| The server can send instant scrolling caption content to the terminal player | |
| Support video, picture and scrolling text to be played in full screen and divided screen | |
| When internet disconnects, the player will play the pre-edited content as a single version machine. | |
| Pictures and text in different sections can be divided flexibly, video section is user-defined. | |
| Support text and picture to be played in scrolling way, support intercut function and timing turning on and off | |
| Various resources can be played, including video,audio file, picture and text. | |
Main features:
1)Adopts high transparent tempered glass as protection layer to prevent LCD panel being broken and distorted.
2)Color for metal outer frame is available with Black color, Shinning-silver color, Golden Color, cream-white color; also we accept customizing color according to color code.
3)Adopts INNOLUX as LCD Panel, Full New A grade standard.
4)Locking system for anti-thieves, prevented the player and storage devices from being stolen
5)Build-in High Quality speakers Stereo 2pcs x 2W.
Applications:
Business Product Promotional display : supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy
Specifications :
| LCD Spec. | LCD Panel Type | 32Inch, 16:9 |
| LCD Resolution | 1920*1080 | |
| Viewing Angle | 178°/178° | |
| Color | 16.7M | |
| Response Time | 6ms | |
| Contrast Ration | 3000:1 | |
| Brightness(cd/m2) | 500 | |
| Player Spec. | Processor | ARM based Multimedia processor |
| Network | 10/100 Mbps Fast Ethernet | |
| Storage | Default 8GB SD card (Maximum up to 128GB) | |
| Wireless | Built-in module of WiFi 802.11b/g or 3G (Optional) | |
| USB Host |
USB2.0 x 1, USB1.0 x 1
|
|
| Power Input | AC 100V~240V 50/60 Hz | |
| Software Spec. | Media Support |
Video / Audio / Picture / Scrolling text/Streaming Video |
| Video format |
MOV, AVI, MP4, DVD, ASF, WMV, MKV, RM, RMVB, TS, DAT, MPG, MPEG,VOB |
|
| Audio format |
MP3, WMA, WMA Pro, AAC, ADPCM, OGG Vorbis, Dolby Digital AC3, Dolby Digital Plus, FLAC |
|
| Picture format | JPEG, BMP, GIF, PNG, TIFF | |
| Scrolling Message (Ticker) |
Horizontal, Adjustable speed, effect, font and background color |
|
| Local Time and Date | Support | |
| Multiple Zones Display | Support multiple zones on screen | |
| Others | Player Dimension | 794 x 484 x 110 mm |
| Power Consumption | 120W | |
| Environmental Factors | Operating temperature: 0-55°C | |
| Relative humidity: 20%-80% | ||
| Color | Silver, Black or any other color | |
| Speaker | built with 2 stereo speaker | |
| Accessories | Wall-mount plate, Remote, Key, Power Cord | |
| Certification |
CE, RoHS, FCC |
Competitive advantages:
We'll guarantee your 100% Satisfaction
Please report us if there are any problem,we will solve it soon
A perfect After-sale system 365 days warranty
Should you have any questions or problems,please send e-mail, call us or talk with us by trade manager.
Professional team and the professional service,we provide OEM/ODM Service.
Our products are sold all over the world, you can rest assured.
