Windows Os Shockproof Free Standing Digital Signage Kiosk 32 Inch Double Screen

Windows Os Shockproof Free Standing Digital Signage Kiosk 32 Inch Double Screen

  • High Light

    self service kiosks

    ,

    digital signage player

  • Resolution
    1920*1080P
  • Operation System
    Windowsor Android
  • Color
    16.7m
  • Brightness
    500cd
  • Warranty
    1 Year
  • Viewing Angle
    178/178
  • Place of Origin
    china
  • Brand Name
    MJK
  • Certification
    CE,Rohs
  • Model Number
    MJK-AD32TKF
  • Minimum Order Quantity
    1pcs
  • Price
    Negotiate
  • Packaging Details
    Packed in carton firstly,and then reinforced with wooden case for outer packing
  • Delivery Time
    3-25days
  • Payment Terms
    T/T
  • Supply Ability
    5000pcs/Month

Windows Os Shockproof Free Standing Digital Signage Kiosk 32 Inch Double Screen



Windows Os Shockproof Free Standing Digital Signage Kiosk 32 Inch Double Screen



Quick Detail:



  • Place of original: Shenzhen Guangdong China(mainland)
  • creen size: 43 "
  • Resolution: 1920 (RGB) × 1080 [FHD]
  • Brightness (cd / m2): 500 (Typ.)
  • Best angle: full view
  • Viewing angle: 89/89/89/89 (Min.) (CR≥10)
  • Point distance: 0.227mm (H) x 0.227mm (W)
  • Number of colors: 16.7M / 1.07B, 95% [CIE1931]
  • Screen Weight: 6.30Kgs (Typ./Max.)
  • Signal system: LVDS (2 ch, 10-bit), terminal, 51 pins
  • Maximum rated: Storage temperature: -20 ~ 60 ° C Operating temperature: 0 ~ 50 ° C
  • Response speed: 6 (Typ.) (G to G) ms
  • Backlight type: WLED, 30K hours, no drive
  • CPU: RK3288, quad-core, frequency 1.6GHz
  • Memory: 1 / 2G (optional)
  • Built-in memory: EMMC FLASH 8G (optional)
  • Built-in ROM: 2KB EEPROM
  • Decoding resolution: up to 1080P
  • Operating system: Android 4.4 above
  • Play mode: support for the cycle, timing, spots and other playback modes
  • Network support: 3G, Ethernet, WiFi support, wireless peripherals expansion
  • Video playback: support wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 and so on
  • Picture format: support BMP, JPEG, PNG, GIF




Description:



⒈Adopts high transparent tempered glass as protection layer to prevent LCD panel being broken and distorted.

⒉Color for metal outer frame is available with Black color, Shinning-silver color, Golden Color, cream-white color; also we accept customizing color according to color code.

⒊Adopts INNOLUX as LCD Panel, Full New A grade standard.

⒋Locking system for anti-thieves, prevented the player and storage devices from being stolen

⒌Build-in High Quality speakers Stereo 2pcs x 2W



Main Features:



⑴ Transparent LCD screen on front side + metal frame.

⑵ Welcome to customize favorable function and hardware, screen size.

⑶ Welcome to customized your favorable shape and color.

⑷ Welcome to customized personal advertising screen with POP, store fixtures design solution.

⑸All products design follow customers' personal ideas, let you own your unique advertising products.



Applications:



1.Public Places:subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums,

museums, convention centers, ticket agencies, HR market, lottery centers;

2.Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers

3.Entertainments:Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course.



Specifications :



1)

LCD Spec. Player Spec.
LCD Panel Type 32Inch, 16:9 Processor ARM based Multimedia processor
LCD Resolution 1368*1050 Network 10/100 Mbps Fast Ethernet
Viewing Angle 178°/178° Storage Default 8GB SD card (Maximum up to 128GB)
Color 16.7M Wireless Built-in module of WiFi 802.11b/g or 3G (Optional)
Response Time 6ms USB Host USB2.0 x 1, USB1.0 x 1
Contrast Ration 3000:1 Power Input AC 100V~240V 50/60 Hz
Brightness(cd/m2) 500



2)

Software Spec. Media Support

Video / Audio / Picture / Scrolling text/Streaming

Video

Video format

MOV, AVI, MP4, DVD, ASF, WMV, MKV, RM, RMVB, TS,

DAT, MPG, MPEG,VOB

Audio format

MP3, WMA, WMA Pro, AAC, ADPCM, OGG Vorbis,

Dolby Digital AC3, Dolby Digital Plus, FLAC

Picture format JPEG, BMP, GIF, PNG, TIFF
Scrolling Message (Ticker)

Horizontal, Adjustable speed, effect, font and

background color

Local Time and Date Support
Multiple Zones Display Support multiple zones on screen





3)

Others Player Dimension 794 x 484 x 110 mm
Power Consumption 120W
Environmental Factors Operating temperature: 0-55°C
Relative humidity: 20%-80%
Color Silver, Black or any other color
Speaker built with 2 stereo speaker
Accessories Wall-mount plate, Remote, Key, Power Cord
Certification

CE, RoHS, FCC





Competitive advantages:



What is your advantage?

1.We can design for you.

2.We can open customers own mold for you.
3.We can offer high quality product & reasonable price for you.
4.We can offer a good after-sale service for you.

5.We have strong and powerful design team.

6.We have quick delivery and small order also welcome.
