LG 47 Inch Transparent LCD Screens Panel , Video / Picture LCD Digital Signage Displays
Quick Detail:
1. LG//AUO/BOE transparent LCD panel
2. Acrylic cooler door
3. Full HD 1080P
4. Flexible size and customization
5. convenient use,delicate appearance.
6. 3G&wifi option Support Transparent video and picture display
Description:
The LD470WUJ is a Color Active Matrix Liquid Crystal Display with an integral the Source PCB and Gate
implanted on Panel (GIP). The matrix employs a-Si Thin Film Transistor as the active element.
It is a transmissive type display operating in the normally black mode. It has a 46.96 inch diagonally measured
act ive display area with WUXGA resolut ion (1080 ver t ical by 1920 hor izontal pixel array) .
Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes.
Gray scale or the luminance of the sub-pixel color is determined with a 10-bit gray scale signal for each dot.
Therefore, it can present a palette of more than 1.07 Billion colors.
It has been designed to apply the 10-bit 2-port LVDS interface.
It is intended to support Public Display where high brightness, super wide viewing angle, high color gamut,
high color depth and fast response time are important. LG 47 Inch Transparent LCD Display
Applications:
MJK LCD digital signage displays are widely used in Business Organizations, Financial Organizations,
Non-profit Organizations, Public Places,Real Estate Property, Entertainments, etc.
Specifications :
| Specification | |
| Active Screen Size | 46.96 inch (1192.87mm) diagonal |
| Outline Dimension | 1061.8(H) x 606.8 (V) x 1.75 mm(D) (Typ.) |
| Pixel Pitch | 0.5415 mm x 0.5415 mm |
| Pixel Format | 1920 horiz. by 1080 vert. Pixels, RGB stripe arrangement |
| Color Depth | 10Bit (D), 1.07 Billion colors |
| Transmittance (With POL) | 5,5 %(Typ.) |
| Viewing Angle (CR>10) | Viewing angle free ( R/L 178 (Min.), U/D 178 (Min.) |
| Power Consumption | Total 6.6W (Typ. |
| Weight | 2.6Kg (Typ.) |
Competitive advantages:
The inside exhibit can be seen while the pictures or videos are displayed on LCD screen. To attract customer's attention on product brand with the combination of dynamic information and the actual product display.
MJK exquisite Transparent Video Showcase can be used in many applications: Jewelry, Gem Stone, Watch, Wine bottle, Cosmetics, Perfume set, Digital Camera, IPad/Mac book, Hand bag, High heel, and Museum Craft, etc.
Our products are sold all over the world, you can rest assured.
