Android Box Transparent Lcd Panel Window Display 22 Inch Lcd Digital Signage
Quick Detail:
1. A Grade LG//AUO/BOE transparent LCD panel
2. Acrylic showcase
3. Flexible size and customization
4. Support Transparent video and picture display
5. convenient use,delicate appearance.
6. 3G&wifi option
7. Compatible foramts: MPEG1,MPEG2,MPEG4,MP3,AVI,JPEG
Description:
MJK-ADT Transparent LCD Display: The inside exhibit can be seen while the pictures or vedios are displayed. It will strength cunstomer’s experience on product brand with the combination of dynamic information and the actual product display is a color active matrix TFT LCD module using amorphous silicon TFT's
(Thin Film Transistors) as an active switching devices. This module has a 15.6 inch
diagonally measured active area with WXGA resolutions (1366 horizontal by 768 vertical
pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in
vertical stripe and this module can display 16.7M colors. The TFT-LCD panel used for this
module is adapted for a low reflection and higher color type.
Applications:
Cooler Door, Indoor, Showcase
Specifications :
| Item | Index |
| Size | 21.5 inch |
| Brand | ,Chimei,BOE etc. |
| Type | MJK-AD21.5T |
| Panel Resolution | 1366(H) *768(V) |
| View Angle | 89/89/89/89(L/R/U/D) |
|
Light transmittance
|
72-82% |
| Color saturation | 72% |
| Display Color | 16.7M |
| Scan Frequency | 60Hz |
| Brightness | 350cd/m2 |
| Contrast Ratio | 5000:1 |
| Response Time | 8ms |
| Active Area | 344.232(H) *193.536(V) |
| Support Audio/Video Coding Format |
MEPG4(AVI, DIVX, XVID),MEPG2(DVD, VOB, mpeg), MEPG1(VCD, DAT, MPG),MP3,JPG ,BMP,GIF,PNG |
| Automatically Turn on/off | Set the on/off time automatically |
| Power Memory |
Support program replaying from the setting time before the power failure |
| Slide Show | Support background music when playing picture |
| Interface Language | Support different languages(Chinese, English, etc.) |
| Play Log |
Support the auto-save of all play records and the save time is adjustable |
| Play Time | Pictures’ playing time can be defined |
| Protect Function |
With safety protection lock, it can prevent replacing CF card at randomly. Support CF card encryption and menu encryption |
| Scroll Caption | Support scrolling caption, effect index can be changed |
| Picture Play Mode | Support the set of a variety of image transition effects |
| File Category Play |
Support disc repeat, single video file repeat, single picture file repeat, etc. |
| Speaker | 2*8Ω2W |
| Calendar&Time |
Support check calendar, adjust time and display it on the screen on/off |
| Installation | Support wall hanging horizontal or vertical |
| Support Memory Medium Type |
Support memory medium type : CF, USB (SD card optional), update through USB |
| Power Protect | Protect type of hidden power switch |
| Dimension(L*W*H)&Net Weight | 962.6mm*585.7mm*13mm & 16Kg |
| Power In& Power Consumption | AC 100-240V 50/60HZ 110W |
Competitive advantages:
The inside exhibit can be seen while the pictures or videos are displayed on LCD screen. To attract customer's attention on product brand with the combination of dynamic information and the actual product display.
MJK exquisite Transparent Video Showcase can be used in many applications: Jewelry, Gem Stone, Watch, Wine bottle, Cosmetics, Perfume set, Digital Camera, IPad/Mac book, Hand bag, High heel, and Museum Craft, etc.
