7 Inch Open Frame LCD Digital Signage Display Retail Store IR Motion Sensor
Quick Detail:
1, Auto play in loop
2, The pannel size optional: 7", 8", 9", 10", 11.6", 12.1, 15.6 "
3, standard VESA, easy to install.
4, Adopt memory card or USB flash disk to update ad files
5. Full HD 1080P
6. Motion sensor function: player starts automatically when the sensor detects an approaching viewer (this function can be disabled or enabled
Description:
Applications:
Our LCD digital signage displays are widely used in Business Organizations, Financial Organizations, Non-profit Organizations, Public Places,Real Estate Property, Entertainments, etc.
Specifications :
All the parameters related to the real products.
Technical Parameter for |
Panel Size |
7 inch LG LCD panel |
Aspect Ratio |
16:9 |
|
Active Area |
304mm(H) x 228mm(V) |
|
Max. Resolution |
800 x 480 |
|
Dot Pitch |
0.297mm(H) x 0.297mm(W) |
|
Number of Color |
16.7M |
|
Brightness |
350cd/m2 |
|
Contrast Ratio |
500:1 |
|
Responsive Time |
5ms |
|
Panel Life |
above 50000 hours |
|
Storage Medium |
Flash memory card |
2gb to 36gb for the capacity |
Support Ad files |
Video formats |
MP4(AVI:DIVX/XVID),MPG2(DVD:VOB/MPG2), MPEG1 (VCD: DAT/MPG1) |
Audio formats |
MP3 |
|
Photo formats |
JPG |
|
OSD Language |
English, Chinese, French, German, Italian, Spanish,Arabic |
|
Audio output |
stereo L/R, 5W*2, 8Ω |
|
Power supply |
AC 110V - 240V, 50/60HZ |
|
Storage Temperature |
-7 to 65 Celsius degree |
|
Normal Working Temperature |
-5 to 65 Celsius degree |
Competitive advantages:
Our lcd digital signage displays are with black full tempered glass to protect the LCD Panel,and also with decorative screws to make it perfect and luxury. Regarding the full-toughened glass, we adopt the silk-screen technology for better quality and appearance.This machine is also designed with MJK board for mounting function,and also with VESA holes for your own bracket.
Our company has our own hardware team and software team, we can provide with the best solution and service.
