1) Material management: audio, video, image, Flash, PPT, Word, Excel, PDF.
2) Program management: program production, editing, management, export/import, playbill / program management.
3) Terminal management: terminal control, rapid release, time synchronization, volume control, download speed, switch, remote updates, touch management,etc.
4) System management: log management, execution status check, password change, user rights management, terminal authentication management.
5) Other functions: user rights designation, terminal authentication management, password change.
Features:
1) Chinese/English OSD menu, easy to operate
2) Aluminium alloy frame, ultra-thin design, easy to use, fashionable appearance
3) Adopt the latest 3D digital decoding and image noise reduction technology
4) Automatic elimination of ghosting function, protecting long-term use of LCD screen
5) A variety of digital images to correct circuit, minimize image distortion
6) 6.7M color depth, image is more natural and smooth
7) 8ms fast response time, no shadow or tail in picture
8) Built-in power supply, low consumption, longer life time
9) Equipped with sensitive infrared receiver, can adjust the parameters of the display via remote control
10) Full metal frame structure design, strong anti-electromagnetic disturbance, no radiation
| Product specifications | ||
| Panel Details | Panel Brand | /LG/AUTO/ LCD/LED/Chimee |
| Panel Size | 32"(7-65 Inch Optional) | |
| IR Touch Screen Details |
Touch Max Resolution | 4096×4096 |
| Transparency | > 90%, Up to 100% | |
| Response Speed | <10ms | |
| Anti-Sunlight/ strong light interference | ||
| Minimum identification point | Minimum identification point | |
| General Information |
Product Color | White,black .color is customized. |
| CPU | Quad-Core RK3288 Cortex-A9 1.6GHz | |
| RAM | 2GB | |
| GPU | Quad-Core version is Mail-400@ 533MHz | |
| ROM ( internal memory ) | 8GB | |
| OS | Android 4.2 or above | |
| Decoding Formats |
Video Format | MPG,MPG-1,MPG-2,MPG-4,AVI,MP4,MOV,WMV,RM,RMVB,etc. |
| FHD 1080P Video | YES | |
| Picture Format | JPG, BMP,PNG,etc. | |
| Text | TXT | |
| Audio Format | MP3,WAV | |
| Interfaces | VGA Output | 1 |
| HDMI Output | 1 | |
| SD/TF card slot | 1 | |
| USB | YES ( two ) | |
| RJ45 | 1 | |
| Additional Functions |
Split Screens,Time and Date,Cloud Streaming,Wifi,LAN ,Update remotely,Weather Function, Live Broadcast,Controlling Software,etc. |
|
| Accessory | Power supply cable, user manual, keys,adapter | |
| Temperature Details:Touch screen operating temperature:-41°C ~70°C,Storage Temperature: -50°C ~85°C The machine operating temperature:-4~65°C,Storage Temperature:-7~65°C. |
||
| Features | ||
| 1.Application fields:public places ,for example,shopping mall, restaurant,airport, square, commercial buidings,etc. | ||
| 2.Outer shell is made of extra good quality metal material, which is painted by powder-spray craft work. | ||
| 3.This machine is of android OS design, which could be connected to internet,and supports remote office cotrol . | ||
| 4.Remotely report system utilization and memory usage. | ||
| 5.Content plays automatically upon set up of schedule. | ||
| 6.Control, monitor and design screen layouts remotely by the remote control office. | ||
| 7.Color for metal outer frame is available with Black color, Shinning-silver color, Golden Color, cream-white color; Color Is Optional. | ||
| 8.Brands of LCD screen for , LG, Chime, HSD, AU, Toshiba etc, A Class 335 standard, full new and factory original packing screen. | ||
| 9.Mounting Way: wall mount, table stand, ground standing method is optional. | ||
1,We have our own ERP of the main manufacturer for digital signage and lcd video wall.
2, We could provide OEM/ODM service for all kinds of customers. Our proffesional support team will service onlin 24 hours for customers.
3, We have a very strong quality control Samples are always available for checking quality and can be dispatched to you very quickly.
4, Samples are always available for checking quality and can be dispatched to you very quickly.
6, Design ability: artwork/ Instruction manual/ product design according to customer's requirement.
7. We have our own ERP systems : Shorten lead times at low cost with responsive production planning
8, Warranty (1-3 year)
MJK ELECTRONICS CO., LTD
was established in 2005. Our company is located in shenzhen, China.Our company is a professional Hi-Tech enterprise engaged in all kinds of LCD digital signage displays such as outdoor kiosks,interactive touch kiosks, touch screen table ,wall mounted displays,floor standing displays,,LCD monitor ,videowall,etc.which are the most widely using media in retail, shopping center, restaurant, hotel, bank, building, airport,showroom etc.
We have a professional and precise technical support team, including software development engineer, electronic engineer, construction engineer, who are outstanding in the digital signage.As one of the leading company in digital signage,MJK offers very innovative, stylish, and full-function products, which are welcome by the clients from over fifty countries and areas.
MJK always takes the strict QMS system to control quality for Zero Fault, so as to meet various standards from clients worldwide. Our products acquire CE, FCC, ROHS,3C certifications so far.
Having rich experience in OEM & ODM cooperation, we are capable of offering you factory price with guaranteed quality as well as complete after-sale service. We have and will always try our best to meet every possible demand of our customers.
Enterprise Vision
We create the best performance to repay the society
Our profassional team and technical capability lead product direction in the future
Be an excellent innovative and competitive company in global market
Our brand has adequate influence in the industry and is well-know in China
We create unique culture and will be the model of Industry
The products and services we offer should be the most reliant and popular in the market
We have excellent team and offer them great workplace and remuneration
Our products are sold all over the world, you can rest assured.
