Supermarket Shopping Mall Outdoor Digital Signage Wall Mounted Stainless Steel shell
1. Quick Detail:
Place of Origin:SHENZHEN,GUANGDONG,CHINA(MAINLAND)
key words:outdoor digital signage
OS:Windows or Android
Sample order:support sample
Type:TFT LCD touch screen with 10points infrared
Application:Outdoor/indoor
Panel Size:65 inch(32"42" 46" 47"55" 65"70"75"82" 84"optional)
Brand Name:MJK
Response Time:6ms
Input Voltage:AC100~240V 50 /60 HZ
Display ratio:16:9
Shell:Galvanized steel sheet.
Max Resolution:1920 * 1080
Viewing Angle:178°/178°(H/V)
Pixel Pitch:0.4845(H)* 0.4845 )
Color:16.7M
Contrast Ratio:2000:1
Brightness:2000cd / m2
2. Description:
| Advertising function |
|
--Air condition cooling system, LCD can used in -35°C--+55°C environment temperature. --We can customize the frame according to your requirements |
| Main Features |
|
--Based on Android 4.4 system(up to 5.1), all the android application apk, software automatic restoration supported. --Real time management and controlling, browser, breakpoint upload download, multi-mode upload supported. --Updating programs (video, pictures. texts, PPT etc.) through the internet supported. --Auto power on/off, electronic clock & date supported. --Split Screen and fixed templated display setting supported. --Setting IP address, working time and working day supported. --1080P full HD programs display supported. --WLAN & LAN long-distance setting play/sleep/reboot etc..function supported. --Display contents cryptographic protection supported (optional). --Cable network, wifi, 3G, 4G touch screen, motion senor and inner camera setting supported (optional). |
| Applications |
|
1.Business Organizations: supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy. 2.Financial Organizations: Banks, negotiable securities, funds, insurance companies, pawnshops; 3.Non-profit Organizations: Telecommunications, post offices, hospital, schools 4.Public Places: subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers; 5.Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers 6.Entertainments:Movie theaters, fitness halls, country clubs, clubs, massage |
3. Specifications :
| Panel Parameter | Panel Size | 55inch (16:9) |
| Active Area | 1428.48*803.52mm | |
| LCD Panel | A grade LCD Panel | |
| Max. Brightness | 2000cd/m² | |
| Max. Resolution | 1920X1080 | |
| Contrast Ratio | 2000:1 | |
| Panel Life | 50000hours | |
| Responsive Time | 6ms | |
| Dot Pitch | 0.4845 mm x 0.4845 mm | |
| Viewing Angle | 178/178 | |
| Interface(I/O) | Build in USB port(2.0), CF card and SD card slot | |
| Power Supply | AC 110V-240V, 50HZ/60HZ | |
| Support Language | Chinese, English,French, Spanish, Korea etc | |
| Product Features | Main Function | Playing file automatically |
| With USB update | ||
| Support LAN,WIFI,3G,4G latest function. | ||
| Support video, pictures and music | ||
| Sercurity and password protection, anti-thief design | ||
| Set up time on/off inadvance | ||
| Support Remote controller | ||
| Support Safety lock system | ||
| Support Media Format | MP4(AVI:DIVX/XVID),MPEG1(VCD:DAT/MPG1) ,MPG2(DVD:VOB/MPG2)MP3,JPG,Txt,Full HD Video output. | |
| Temperature |
Storage:-40Celsius degree to 5 Celsiucs degree Working: -30Celsius degree to 55 Celsius degree |
|
| Fixing Method | Free Standing/wall mounting | |
| Color | Shinning Silver(Optional for particularly color) | |
| Housing Material | 5mm thickness tempered glass as LCD panel protection layer | |
| Applicable field | Supermarket, Hotel,Mall center, Shop, Commercial buildings ,Bus station etc. | |
| Packing information | Packaging Size(mm) | Subject to specific products |
| N.W. / G. W. (kg) | 96kg/ 110kg | |
| Packing Material | Carton and Wooden package together | |
| Competitive advantages |
|
----Sunshine readable, high brightness 2000 nits, auto dimming. ----Waterproof ----Anti- thief, Anti dust. ----Application areas can be public bus station, out of shopping mall, store, etc. ----Certification: IP65 level ----Built-in air conditioner and fans optional. |
Our products are sold all over the world, you can rest assured.
