Quick Detail:
Place of Origin:SHENZHEN,GUANGDONG,CHINA(MAINLAND)
Brand Name:MJK
Response Time:6ms
Input Voltage:AC100~240V 50 /60 HZ
Display ratio:16:9
Shell:Galvanized steel sheet.
key words:outdoor digital signage
OS:Windows or Android
Sample order:support sample
Type:TFT LCD touch screen with 10points infrared
Application:Outdoor/indoor
Panel Size:65 inch(32"42" 46" 47"55" 65"70"75"82" 84"optional)
Max Resolution:1920 * 1080
Viewing Angle:178°/178°(H/V)
Pixel Pitch:0.4845(H)* 0.4845 )
Color:16.7M
Contrast Ratio:2000:1
Brightness:2000cd / m2
Description:
- Intelligent light system, brightness of screen auto adjusts according to environment light, saving energy.
- Waterproof, Anti-dust, anti-vandal, anti-theft.
- Build in Air-conditioner cooling system, adapted to -35°C--+55°C environment temperature.
- Front tempered glass and anti-glare glass.
- Wall mounted, hanging and free standing(fixed on ground) all available.
- Main outer shell is made by extra quality Iron material, side frame adopts Aluminium Alloy Mould, front frame adopts 4-6mm thickness Tempered glass, which can protect the LCD panel.
- Using professional FHD multimedia discoed chips, high frequency cup
- DC12V input, industry design, lower power consumption, stable and anti-interference
Main Features:
- Outdoor advertising player can be combined with the touchscreen technology, all-in-one PC, security monitor system ect.
- Auto power on or off.
- IP65 design for outdoor application.
- High brightness up to 2000cd/m2, readable under sunlight.
- Lightning protection and heating below zero.
-
Customized design for you without additional cost.
Applications:
Public Service: Hospital, School, Telecom, Post office;Public Places: Subway, Airport, Bookshop, Exhibition hall, Gymnasium, Museum, Conference center, Talent market, Lottery center;
Entertainment Places:Movie theatre, Fitness center, Vacational village, KTV bar, Internet bar, Beauty salon, Golf course;
Financial Institution: Bank, Security/ Fund/ Insurance company;Real Estate&Property: Apartment, Villa, Office building, Commercial office buildings, Model houses, Sales offices, the entrance of elevator, etc.
Business Organizations: Supermarket, Shopping malls, Exclusive shop, chain store, 4S shop, Hotel, Restaurant, travel agency, Chemist's shop;etc
Specifications :
| Panel Parameter |
Panel Size |
55inch (16:9) |
| Active Area |
1428.48*803.52mm |
| LCD Panel |
A grade LCD Panel |
| Max. Brightness |
2000cd/m² |
| Max. Resolution |
1920X1080 |
| Contrast Ratio |
2000:1 |
| Panel Life |
50000hours |
| Responsive Time |
6ms |
| Dot Pitch |
0.4845 mm x 0.4845 mm |
| Viewing Angle |
178/178 |
| Interface(I/O) |
Build in USB port(2.0), CF card and SD card slot |
| Power Supply |
AC 110V-240V, 50HZ/60HZ |
| Support Language |
Chinese, English,French, Spanish, Korea etc |
| Product Features |
Main Function |
Playing file automatically |
| With USB update |
| Support LAN,WIFI,3G,4G latest function. |
| Support video, pictures and music |
| Sercurity and password protection, anti-thief design |
| Set up time on/off inadvance |
| Support Remote controller |
| Support Safety lock system |
| Support Media Format |
MP4(AVI:DIVX/XVID),MPEG1(VCD:DAT/MPG1) ,MPG2(DVD:VOB/MPG2)MP3,JPG,Txt,Full HD Video output. |
| Temperature |
Storage:-40Celsius degree to 5 Celsiucs degree
Working: -30Celsius degree to 55 Celsius degree
|
| Fixing Method |
Free Standing/wall mounting |
| Color |
Shinning Silver(Optional for particularly color) |
| Housing Material |
5mm thickness tempered glass as LCD panel protection layer |
| Applicable field |
Supermarket, Hotel,Mall center, Shop, Commercial buildings ,Bus station etc. |
| Packing information |
Packaging Size(mm) |
Subject to specific products |
| N.W. / G. W. (kg) |
96kg/ 110kg |
| Packing Material |
Carton and Wooden package together |
Competitive advantages:
Metal outer shell, silver/Black color etc <can optional>
With a protection layer of ultra-thin, high light-penetrating toughened glass on the surface of the screens
With USB update feature; support functions between the card and card copying files.
Playing advertising program automatically and circular.
|
